Hacking my XP-Pen drawing tablets

Posted on by nek0 in hardware, hacking, drawing

Hi there,

Long time no see. I am currently quite busy finishing my apprenticeship so my free time suffers a bit, but my goal is now in reach. Only my oral exam is left to pass and then I will be done.

So today I want to write about some hardware issues I had with my drawing tablets and which I solved thanks to this blog post by David Revoy.

I have been drawing digitally a lot in my free time and thus own at least one drawing tablet. I stuck with the brand “XP-Pen” as they seem to have a fairly good quality for a reasonable price. Also they seem to support linux (at least in their own strange way). They do ship a driver for their tablets, which is proprietary and needs to run in the background all the time and seems not to be able to remember its settings (at least not on my NixOS).

So up until recently I was bound to work with what worked out of the box with Deco Pro M, which was most of the functionality it provided, even the pen tilt was recognized out of the box. The only things I was missing was making a right-click with my pen, assigning the hotkeys on my tablet and mapping the tablet to a specific Display on a multi monitor setup.

This is where David’s blog post enters the stage, where he provides a detailed guide on how to set up a XP-Pen Artist 24 drawing monitor in linux without using the proprietary driver. I was able to extrapolate from that and adjust my /etc/nixos/configuration.nix to configure my tablet according to my needs.

What I want to try with this blog post is to provide a more general guide on how to configure most, if not any, XP-Pen drawing tablets or monitors on NixOS.

The procedure

First of all, You need to find out the identifier for your tablet. with the tablet plugged into the USB port, run lsusb (which is part of the usbutils package). You should get some lines of output with an entry similar to this one:

Bus 001 Device 005: ID 28bd:0904 XP-Pen 11 inch PenTablet

The 28bd:0904 is the ID we are looking for. Note that the part after the colon varies from device to device, so don’t just copy&paste.

Now we enter the realm of the configuration. First of all, we need to enable the digimend driver with the following settings:

services.xserver.digimend.enable = true;

Now we move on to having the wacom driver actually manage the XP-Pen devices. For this we have to add rules to the Xorg.conf, which is conveniently handled like this:

services.xserver.inputClassSections = [
    Identifier "XP-Pen 11 inch PenTablet"
    MatchUSBID "28bd:0904"
    MatchIsTablet "on"
    MatchDevicePath "/dev/input/event*"
    Driver "wacom"
    Identifier "XP-Pen 11 inch PenTablet"
    MatchUSBID "28bd:0904"
    MatchIsKeyboard "on"
    MatchDevicePath "/dev/input/event*"
    Driver "libinput"

These two sections match to my tablet, so alter all occurences of the lines Identifier and MatchUSBID to match your device, otherwise it will not work.

With this you tell your system to let the wacom driver handle all tablet input it can handle, everything else will be interpreted as a keyboard by libinput, which includes all the hotkeys on your tablet, if you have any.

Now comes the fun part mapping the upper stylus button to be a right-click. For this we need to analyse the input of the stylus using evtest (which is contained within the package of the same name). With root permissions we run evtest and see output containing lines similar to this:

/dev/input/event21:	11 inch PenTablet Mouse
/dev/input/event22:	11 inch PenTablet Keyboard
/dev/input/event23:	11 inch PenTablet
Select the device event number [0-23]:

Select the device without Mouse or Keyboard, so 23 in this example.

You will get an overview of all input events supported by this device and when you bring your stylus near the pad it should pick up all movements and button presses you make and print them onto the console. To abort this testing, press Ctrl + C on your keyboard.

Depending on your device, the output of the stylus test will produce a lot of output, because all position and tilt changes will be recorded onto the console. what we are looking for though is the input of the upper stylus button, so press it a few times trying to hold the pen as steady as possible and abort shortly after your button presses.

Now you need to look for specific lines in the console output, which will look somewhat like this:

Event: time 1624813216.995575, type 4 (EV_MSC), code 4 (MSC_SCAN), value d0045

The most important keyword here is the code 4 (MSC_SCAN), so search for that, and note the value behind it. In this case it is d0045. This value, by the way, seems to be the standard value for the right-click with XP-Pen tablets, as it is the same with all three tablets or monitors I have set up with this method so far.

After we extracted the right-click value of the stylus, let’s return to our configuration file and add the following option:

services.udev.extraHwdb = ''

This rule will do the actual remapping of the button press on the stylus to right-click. Note, that the USB-ID of your device is present in here too, so change this line so it matches your device:


The line below contains the value of the upper stylus button (d0045) and maps it to the right-click value (0x14c).

Congratulations. You just configured right-click on your stylus.

To map your hotkeys on your tablet, you need to run evtest again, but this time you want to test the device with the keyboard description. Press your hotkeys and note the values behind the code 4 (MSC_SCAN) lines.

Then remap the values to your desired keys. Note that not all hotkeys support multikey bindings, but only those emitting multiple different keypress codes.

I hope this tutorial is helpful for you in any way. If you feel that I missed something or need some clarification, just get in touch and I will expand this article as needed.

Keep calm and wash hands.

Errata and Addenda

How to map your tablet input to a specific monitor

I completely forgot to write about this part. The most generic way to do this is to find out the ID of your stylus via xinput, and then the number of the graphics output you want to map it to using xrandr --listactivemonitors. You are interested in the number prefacing the monitor/connection descriptor.

After accomplishing this, you enter the following command:

xinput map-to-output <Stylus-ID> HEAD-<Output-No>

Wrong driver activation

In the article I stated to enable the wacom driver, which actually is not absolutely needed, but I forgot to mention the digimend driver, Which is activated by this setting:

services.xserver.digimend.enable = true;

The according section in the article has also been corrected.
